Assa Abloy SW300 (Pair)

ASSA ABLOY SW300 Automatic Swing Door Operators (Pair) – Double Door Kit

The ASSA ABLOY SW300 Double Operator Kit includes two SW300 swing door operators, designed to automate a pair of swing doors in a coordinated and compliant manner. Ideal for double-leaf entrances, this kit delivers exceptional performance, durability, and flexibility for high-traffic and fire-rated door applications.

With support for door weights up to 450 kg per leaf, the SW300 system offers quiet operation, advanced safety features, and full compliance with EN16005 and other accessibility standards. This kit is suitable for use in commercial buildings, hospitals, care homes, and public facilities where reliability and safety are paramount.

Inc Sync Cable L1200

Key Features & Benefits

Complete Pair for Double Doors
Supplied as a matched set of 2x SW300 operators, ideal for automating dual swing door sets with or without a central rebated stile.

High Load Capacity – Up to 450 kg per Leaf
Each operator is capable of managing heavy, wide doors independently, with coordinated control available via external selectors or master/slave logic.

Fire Door Compatible
Suitable for use on fire-rated doors when installed with approved accessories. Optional mechanical or electrical coordinator kits available.

Flexible Mounting – Push or Pull
Each operator can be configured for push or pull arm installations depending on site requirements.

Quiet, Smooth Automation
Electro-mechanical drive offers near-silent operation, ideal for healthcare and interior environments where noise must be minimised.

Advanced Safety & Obstacle Detection
Full compliance with EN16005, with built-in safety logic, obstruction detection, and reverse-on-block functionality.

Customisable Operation Modes
Selectable low-energy or fully automatic function with adjustable speeds, hold times, and push & go features.

Technical Summary (Per Operator)

• Power Supply: 100–240 V AC, 50/60 Hz

• Motor Type: Electro-mechanical, 24 V DC

• Max Door Weight: Up to 450 kg

• Max Door Width: Up to 1600 mm

• Max Inertia:
    • Push arm: 140 kg·m²
    • Pull arm: 80 kg·m²

• Mounting: Surface-mounted (push or pull)

• Operating Temp: –20 °C to +45 °C

• Ingress Protection: IP20

• Compliance: EN16005, EN1634, EN1158, DIN 18263-4

• Supports: Fire door coordination, battery backup, safety sensors, key/programme selectors

Applications

• Double swing door entrances

• Commercial buildings and office receptions

• Hospitals, care homes, and public sector facilities

• Fire escape doors and internal protected routes

• Doors requiring DDA/Equality Act compliance

The ASSA ABLOY SW300 Dual Operator Kit provides a robust, high-specification solution for automating double swing door systems, combining strength, safety, and seamless performance in one complete
